Saftey limit - alarm units

LHI.LHL

Click image for datasheet

LHL: LIMITROL® (48x48 mm)
- INPUT TC, 3 WIRES RTD AND LINEAR mA / mV / V
- APPROVED SAFETY FUNCTIONS
- 2X HIGH/LOW LIMIT ALARMS WITH RESET FUNCTION
- TIME-IN-RESET MEMORY
- RS485 SERIAL INTERFACE
- DIN RAIL MOUNTING VERSION
- IP65 AND NEMA 4X FRONT PROTECTION

LHI: INDICATOR (48x48 mm)
- INPUT TC, 3 WIRES RTD AND LINEAR mA / mV / V
- APPROVED SAFETY FUNCTIONS
- 2 HIGH/LOW LIMIT ALARMS WITH RESET FUNCTION
- RS485 SERIAL INTERFACE
- DIN RAIL MOUNTING VERSION
- IP65 AND NEMA 4X FRONT PROTECTION

Indicators

TIS

Click image for datasheet

TIS / TIS MK1: PROGRAMMABLE INDICATOR (96x48 mm)
- INPUT, TC, 3 WIRES RTD AND LINEAR mA / mV / V
- INPUT FILTER AND RANGE SCALING
- ISOLATED PV RETRANSMISSION (mA)
- ISOLATED 24V TRANSMITTER POWER SUPPLY
- 2 or 3 INDEPENDENT ALARMS
- PEAK MAX/MIN LEVEL MEMORY
- IP65 AND NEMA 4X FRONT PROTECTION

DPS

Click image for datasheet

DPS: PROGRAMMABLE INDICATOR & TRANSMITTER (96x48 mm)
- INPUT TC, 3 WIRES RTD AND LINEAR mA / mV / V
- INPUT FILTER AND RANGE SCALING
- ISOLATED PV RETRANSMISSION (mA)
- 2 INDEPENDENT ALARMS
- PEAK MAX/MIN LEVEL MEMORY
- 10-POINT LINEARISATION AND SQUARE ROOT
- ISOLATED 24V TRANSMITTER POWER SUPPLY
- RS485 SERIAL INTERFACE
- IP65 AND NEMA 4X FRONT PROTECTION

DPL

Click image for datasheet

DPL: PROGRAMMABLE INDICATOR & TRANSMITTER (96x48 mm)
- MAIN INPUT LINEAR mA / V
- DIGITAL INPUT
- ISOLATED PV RETRANSMISSION
- ISOLATED 24V TRANSMITTER POWER SUPPLY
- 2 INDEPENDENT ALARMS
- PEAK MAX/MIN LEVEL MEMORY
- RS485 SERIAL INTERFACE
- IP65 AND NEMA 4X FRONT PROTECTIONrature
